Airwell K 45 OG [6/16] Heating capacities

Page 6

Heating Capacities

Size 30 - 2 pipes Size 45 - 2 pipes

Air flow (m

/h) Air flow (m

/h)

LS MS HS LS MS HS

1100 1350 1550 1060 1360 1725

70/60 °C

19 °C PC W 13904 15727 18641 12981 16446 20288

20 °C PC W 13567 15344 18186 12663 16042 19784

21 °C PC W 13231 11960 17738 12348 15645 19292

EUROVENT

7000 7770 8050 7192 8927 11600

50/40 °C

19 °C PC W 7651 8638 10222 7100 8016 11171

20 °C PC W 7324 8272 9784 6797 7676 10697

21 °C PC W 7000 7900 9354 6496 7331 10218

Size 45 - 4 pipes

Air flow (m

/h)

LS MS HS

1075 1360 1725

70/60 °C

19 °C PC W 6919 7924 9022

20 °C PC W 6756 7737 8808

21 °C PC W 6593 7551 8601

60/50 °C

19 °C PC W 5335 6110 6860

20 °C PC W 5209 6020 6676

21 °C PC W 5083 5873 6578

50/40 °C

19 °C PC W 3782 4317 4014

20 °C PC W 3601 4134 4705

21 °C PC W 3434 3949 4497

PC : Heating capacity (W).
