11
The unit is designed to be connected to a duct work. Should it not be the case, a discharge protection grille and
a device creating sufficient pressure drop must be supplied by the installer to avoid excess current draw generated
at the motor (see blower curves in the appendix)
4 discharges and 4 intakes air configurations are available.
For each configuration, note the dimensions of the discharge air duct to be provided before the unit arrives on site.
Make sure that it is fireproof and that it does produce toxic smoke in the event of a fire in the building. The interior
surfaces must be smooth and cleanable to avoid contamination of the circulated air.
CONFIGURATION OF THE UNIT
GENERALITES
NEVER DRILL ANY HOLES IN THE AIR TREATMENT ZONE OF THE UNIT. THE
MANUFACTURER’S WARRANTY WILL BE CANCELLED IN THE EVENT OF ANY
WATER LEAKS RESULTING FROM THE DRILLING OF HOLES IN THE CASING.
Downward discharge: S1
¢
Sideway discharge: S2 ¢
Front discharge: S3 ¢
Top discharge: S4 ¢
SUPPLY AIR
The "Downward discharge" and "Return air from below" versions requires the presence of a roof curb. For all cases,
the installation must be analysed to avoid any risk of damage to the support on which the unit will be mounted,
given its weight, .
DIMENSIONS
SEE APPENDIX
Return air from below: R1 ¢
Return air from the side: R2 ¢
Return air from the rear: R3 ¢
Return air from the top: R4 ¢
AIR INTAKE
