PRESSOSTATS SETTING
Refrigerant circuit
Factory low pressure adjustment 2bars (29PSI)
Factory high pressure adjustment 42bars (609.16PSI)
Clogged filter
ΔP warning (upstream/downstream filters) > 250 Pa
Airflow detector ΔP warning (upstream/downstream blower)< 50 Pa
RANGE AND SETTINGS OF THEMAL PROTECTION / NOMINAL INTENSITY OF THE
CONTACTORS (CLASSE AC3)
COMPRESSORS CRANKCASE HEATER
Models 40 50 60 70 80 100 110
Power W 70 90 90 90 75 90+75 75
Model
40 50 60 70 80 100 110
PE GE PE GE PE GE PE GE PE GE PE GE PE GE
Q1 Range
13-18A 17-23A 17-23A 24-32A 25-40A 25-40A 25-40A
Adjustment
15A 18A 21A 23A 35A 35A 38A
Q2 Range
13-18A 17-23A 17-23A 24-32A 25-40A 25-40A 25-40A
Adjustment
15A 18A 21A 23A 35A 38A 38A
Q3 Range
4-6.3A 9-14A 4-6.3A 9-14A 9-14A 13-18A 9-14A 13-18A 13-18A 13-18A 13-18A 13-18A 13-18A 13-18A
Adjustment
4A 10.9A 4.8A 11A 11A 14.8A 11A 14.8A 14.8A 15.6A 15.5A 16.3A 15.5A 16.3A
Q4
6A 6A 6A 6A 6A 6A 6A
Q7/8 Range
/////2.5-4A 2.5-4A
Adjustment
/////2.5A 2.5A
FT1
10A 10A 2A 2A 2A 2A 2A
FT3
/ / 10A 10A 10A / /
FT4
/ / 10A 10A 10A / /
Contactor AC3
KM1
18A 18A 25A 25A 40A 40A 40A
KM2
18A 18A 25A 25A 40A 40A 40A
KM3
9A 12A 9A 12A 12A 18A 12A 18A 18A 18A 18A
KM4
9A 9A 9A 9A 9A 9A 9A
KM7
9A 9A 9A 9A 9A 6A 6A
KM8
/ / 9A 9A 9A 6A 6A
SWS : Winter/Summer switch (not supplied)
KM1/2 : C1/2 compressors power contactor
KM3/4/7/8 : Fan power contactors
K5/6 : Heating elements power contactors (option)
EV1/2 : Circuits 1 and 2 cycle inversion valve (option)
KA2/3 : Relay contactors of the outdoor fan (option "all seasons"/ heat pump mode)
