Page 10
Physical Data SLH 1202 to 2202 - LN Version
(1) Data based on leaving chilled water temperature of 7 °C and ambient air temperature of 35 °C.
(2) Data based on leaving hot water temperature of 45 °C and ambient air temperature of 7 °C/88 % HR.
(3) Data given for compressors only.
(4) Sound levels given at fully loaded conditions. Sound power level values refer to ISO 3744 and Eurovent 8/1.
(5) Sound pressure level values refer to ISO 3744.
SLH LN models 1202 1402 1602 1802 1902 2002 2202
Nominal cooling capacity (1) kW 247.5 282.2 313.5 340.7 384.1 400.2 436.2
Power input (3) kW 107.8 113.8 132.5 145.4 155.0 164.9 185.1
EER 2.3 2.5 2.4 2.3 2.5 2.4 2.4
Nominal heating capacity (2) kW 278.6 312.9 348.8 380.8 427.7 456.4 484.8
Power input (3) kW 96.0 106.3 118.8 132.5 140.7 156.0 160.4
COP 2.9 2.9 2.9 2.9 3.0 2.9 3.0
Number of refrigerant circuits 2222222
Number of capacity steps
Compressors
Number 2222222
Type
Evaporators
Number 1111111
Type
Water content per evaporator litres 26 26 33 40 40 40 50
Condensers
Number of coils 4444444
Face area per coil m
2
4444446
Number of rows 3333443
Fans
Number of fans 4668888
Nominal fan speed rpm 700 700 700 700 700 700 700
Total air flow m
3
/h 67 000 94 000 94 000 112 500 105 000 105 000 128 000
Total power kW 8.0 12.0 12.0 16.0 16.0 16.0 16.0
Weight
Shipping weight kg 3540 3960 4000 4075 4510 4880 5600
Operating weight kg 3566 3986 4033 4115 4550 4920 5650
Sound levels
Sound power levels (4) dB(A) 91.0 92.0 92.0 92.0 92.0 92.0 92.0
Sound pressure levels at 10 m (5) dB(A) 59.0 60.0 60.0 60.0 60.0 60.0 60.0
Dimensions
Length mm 4030 4030 4030 4030 4030 4030 6030
Width mm 2200 2200 2200 2200 2200 2200 2200
Height mm 2550 2550 2550 2550 2550 2550 2550
6
Twin screw
Plate
