Page 11
Physical Data SLH 2402 to 3804 - LN Version
(1) Data based on leaving chilled water temperature of 7 °C and ambient air temperature of 35 °C.
(2) Data based on leaving hot water temperature of 45 °C and ambient air temperature of 7 °C/88 % HR.
(3) Data given for compressors only.
(4) Sound levels given at fully loaded conditions. Sound power level values refer to ISO 3744 and Eurovent 8/1.
(5) Sound pressure level values refer to ISO 3744.
SLH LN models 2402 2602 2804 3204 3604 3804
Nominal cooling capacity (1) kW 453.4 503.1 564.4 627.0 681.5 740.9
Power input (3) kW 194.8 211.4 227.6 265.0 290.8 310.3
EER 2.3 2.4 2.5 2.4 2.3 2.4
Nominal heating capacity (2) kW 512.8 561.0 625.8 697.6 761.5 837.1
Power input (3) kW 183.2 189.9 212.6 237.6 265.0 288.5
COP 2.8 3.0 2.9 2.9 2.9 2.9
Number of refrigerant circuits 224444
Number of capacity steps
Compressors
Number 224444
Type
Evaporators
Number 112222
Type
Water content per evaporator litres 50 50 26/26 33/33 40/40 40/40
Condensers
Number of coils 448888
Face area per coil m
2
668888
Number of rows 343333/4
Fans
Number of fans 8 8 12 12 16 16
Nominal fan speed rpm 700 700 700 700 700 700
Total air flow m
3
/h 128 000 125 000 188 000 188 000 225 000 217 500
Total power kW 16.0 16.0 24.0 24.0 32.0 32.0
Weight
Shipping weight kg 5960 6230 7920 8000 8150 8955
Operating weight kg 6010 6280 7973 8066 8230 9035
Sound levels
Sound power levels (4) dB(A) 92.0 92.0 95.0 95.0 95.0 95.0
Sound pressure levels at 10 m (5) dB(A) 60.0 60.0 63.0 63.0 63.0 63.0
Dimensions
Length mm 6030 6030 8400 8400 8400 8400
Width mm220022002200220022002200
Height mm 2550 2550 2550 2550 2550 2550
Twin screw
Plate
612
