Airwell SLH 1402 [20/40] Sound data
![Airwell SLH 1202 [20/40] Sound data](/views2/1409183/page20/bg14.png)
Page 20
Sound Data
SLH 1202 to 3804 - BLN Version
(*) Sound pressure levels given at 10 meters in free field conditions according to ISO 3744.
SLH 1202 to 3804 - LN Version
(*) Sound pressure levels given at 10 meters in free field conditions according to ISO 3744.
125 250 500 1000 2000 4000 8000
1202
90.0 89.0 96.8 90.5 85.0 69.5 58.3 96 64
1402
91.0 90.0 97.8 91.5 86.0 70.5 59.3 97 65
1602
91.0 90.0 97.8 91.5 86.0 70.5 59.3 97 65
1802
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
1902
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
2002
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
2202
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
2402
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
2602
92.0 91.0 98.8 92.5 87.0 71.5 60.3 98 66
2804
94.0 93.0 100.8 94.5 89.0 73.5 62.3 100 68
3204
94.0 93.0 100.8 94.5 89.0 73.5 62.3 100 68
3604
95.0 94.0 101.8 95.5 90.0 74.5 63.3 101 69
3804
95.0 94.0 101.8 95.5 90.0 74.5 63.3 101 69
SLH models
Frequencies (Hz)
Lw global
dB(A)
Lp global
dB(A) *
125 250 500 1000 2000 4000 8000
1202
85.0 84.0 91.8 85.5 80.0 64.5 53.3 91 59
1402
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
1602
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
1802
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
1902
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
2002
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
2202
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
2402
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
2602
86.0 85.0 92.8 86.5 81.0 65.5 54.3 92 60
2804
89.0 88.0 95.8 89.5 84.0 68.5 57.3 95 63
3204
89.0 88.0 95.8 89.5 84.0 68.5 57.3 95 63
3604
89.0 88.0 95.8 89.5 84.0 68.5 57.3 95 63
3804
89.0 88.0 95.8 89.5 84.0 68.5 57.3 95 63
SLH models
Frequencies (Hz)
Lw global
dB(A)
Lp global
dB(A) *
