Page 18
Electrical Data - SLH 2804 to 3804
Compressors electrical data
Fans electrical data
SLH
models
Circuits
Starting
type
(*)
Power input
at nominal
conditions
(kW)
Curr. input
at nominal
conditions
(A)
Power input
at max.
conditions
(kW)
Curr. input
at max.
conditions
FLA (A)
Starting
current
LRA (A)
Crankase
heater
230 V/1 Ph
(W)
Nominal
power
factor
1 P / W 56.9 101.5 67.7 124.0 280.0 200.0 0.81
2 P / W 56.9 101.5 67.7 124.0 280.0 200.0 0.81
3 P / W 56.9 101.5 67.7 124.0 280.0 200.0 0.81
4 P / W 56.9 101.5 67.7 124.0 280.0 200.0 0.81
1 P / W 65.1 116.1 77.4 140.0 351.0 200.0 0.81
2 P / W 65.1 116.1 77.4 140.0 351.0 200.0 0.81
3 P / W 65.1 116.1 77.4 140.0 351.0 200.0 0.81
4 P / W 65.1 116.1 77.4 140.0 351.0 200.0 0.81
1 P / W 75 129.0 96 162.0 423.0 200.0 0.84
2 P / W 75 129.0 96 162.0 423.0 200.0 0.84
3 P / W 75 129.0 96 162.0 423.0 200.0 0.84
4 P / W 75 129.0 96 162.0 423.0 200.0 0.84
1 P / W 87 149.7 110 180.0 520.0 300.0 0.84
2 P / W 87 149.7 110 180.0 520.0 300.0 0.84
3 P / W 75 129.0 96 162.0 423.0 200.0 0.84
4 P / W 75 129.0 96 162.0 423.0 200.0 0.84
2804
3204
3804
3604
SLH models 2804 3204 3604 3804
Number of fans 12 12 16 16
Nominal power per fan kW2222
Maximum running current A4444
Total power kW 24.0 24.0 32.0 32.0
Total maximum current A 48.0 48.0 64.0 64.0
Standard fans - BLN & LN versions
SLH models 2804 3204 3604 3804
Nombre de ventilateurs 12161616
Nominal power per fan kW 1.25 1.25 1.25 1.25
Maximum running current A 2.3 2.3 2.3 2.3
Total power kW 15.0 20.0 20.0 20.0
Total maximum current A 27.6 36.8 36.8 36.8
Standard fans - ELN version
SLH models 2804 3204 3604 3804
Number of fans 12 16 16 16
Standard fans - HET version
Nominal power per fan kW2222
Maximum running current A4444
Total power kW 24.0 32.0 32.0 32.0
Total maximum current A 48.0 64.0 64.0 64.0
(*) P/W : Part-Winding.
