Page 17
Units electrical data
Electrical Data - SLH 1202 to 2602 (cont'd)
SLH BLN & LN models 1202 1402 1602 1802 1902 2002 2202 2402 2602
Maximum current input A 208.0 272.0 304.0 356.0 368.0 392.0 424.0 464.0 482.0
Maximum power input kW 124.6 147.4 166.8 208.0 203.0 236.0 241.2 280.0 280.6
Maximum starting current A 456.2 390.8 473.0 568.4 644.6 678.0 445.2 497.2 543.5
Unit aM fuses A 315 315 315 400 400 400 500 500 630
Phase cable cross section
mm
2
240 240 240 2 x 120 2 x 120 2 x 120 2 x 150 2 x 150 2 x 185
SLH ELN models 1202 1402 1602 1802 1902 2002 2202 2402 2602
Maximum current input A 205.8 261.8 298.4 342.4 354.4 383.0 410.4 455.0 473.0
Maximum power input kW 124.1 142.9 164.8 202 197 232.5 235.2 276.5 277.1
Maximum starting current A 454 380.6 467.4 554.8 631 669 431.6 488.2 534.5
Unit aM fuses A 315 315 315 400 400 400 500 500 630
Phase cable cross section
mm
2
240 240 240 2 x 120 2 x 120 2 x 120 2 x 150 2 x 150 2 x 185
SLH HET models 1202 1402 1602 1802 1902 2002 2202 2402 2602
Maximum current input A 216.0 272.0 312.0 356.0 368.0 400.0 424.0 472.0 490.0
Maximum power input kW 128.6 147.4 170.8 208 203 240 241.2 284 284.6
Maximum starting current A 464.2 390.8 481 568.4 644.6 686 445.2 505.2 551.5
Unit aM fuses A 315 315 315 400 400 500 500 500 630
Phase cable cross section
mm
2
240 240 240 2 x 120 2 x 120 2 x 150 2 x 150 2 x 150 2 x 185
