Correction Factors
Fouling factors
Altitude factors
Altitude (m) Cooling capacity factor Power input factor
0 1.000 1.000
600 0.987 1.010
1200 0.973 1.020
1800 0.958 1.029
2400 0.943 1.038
Fouling factor (m
2
.°C/kW)
Cooling capacity factor Power input factor
0.044 1.000 1.000
0.088 0.987 0.995
0.176 0.964 0.985
0.352 0.915 0.962
EVAPORATOR
Fouling factor (m
2
.°C/kW)
Cooling capacity factor Power input factor
0.044 1.000 1.000
0.088 0.987 1.023
0.176 0.955 1.068
0.352 0.910 1.135
CONDENSER
