Chillers
TURBOCHILL
Installation Manual : 6703052 05/2008
Chillers
11
A B C D E F G H J K L M
TCC1xxx08Xxx mm 2600 2200 4675 500 1250 1250 1250 - - 425 1082 2360
TCC1xB110Xxx mm 2600 2200 5676 500 1750 1250 1750 - - 425 1582 2360
TCC1xB210Xxx mm 2600 2200 5676 500 1750 1250 1750 - - 425 1582 2360
TCC1xC110Xxx mm 2600 2200 5676 500 1750 1250 1750 - - 425 1307 2910
TCC1xD110Xxx mm 2600 2200 5676 500 1750 1250 1750 - - 425 1157 3210
TCC1xD210Xxx mm 2600 2200 5676 500 1750 1250 1750 - - 425 1157 3210
TCC1xB112Xxx mm 2600 2200 7100 500 1850 1200 1175 1775 - 600 2730 2360
TCC1xB212Xxx mm 2600 2200 7100 500 1850 1200 1175 1775 - 600 2730 2360
TCC1xC112Xxx mm 2600 2200 7100 500 1850 1200 1175 1775 - 600 2455 2910
TCC1xD112Xxx mm 2600 2200 7100 500 1850 1200 1175 1775 - 600 2305 3210
TCC1xD112Xxx mm 2600 2200 7100 500 1850 1200 1175 1775 - 600 2305 3210
TCC1xB114Xxx mm 2600 2200 8100 500 2000 1400 1400 2000 - 800 2730 2360
TCC1xB214Xxx mm 2600 2200 8100 500 2000 1400 1400 2000 - 800 2730 2360
TCC1xC114Xxx mm 2600 2200 8100 500 2000 1400 1400 2000 - 800 2455 2910
TCC1xD114Xxx mm 2600 2200 8100 500 2000 1400 1400 2000 - 800 2305 3210
TCC1xD214Xxx mm 2600 2200 8100 500 2000 1400 1400 2000 - 800 2305 3210
TCC1xB116Xxx mm 2600 2200 9100 500 2875 1400 1400 2325 - 600 3730 2360
TCC1xB216Xxx mm 2600 2200 9100 500 2875 1400 1400 2325 - 600 3730 2360
TCC1xC116Xxx mm 2600 2200 9100 500 2875 1400 1400 2325 - 600 3455 2910
TCC1xD116Xxx mm 2600 2200 9100 500 2875 1400 1400 2325 - 600 3305 3210
TCC1xD216Xxx mm 2600 2200 9100 500 2875 1400 1400 2325 - 600 3305 3210
TCC1xB118Xxx mm 2600 2200 10100 500 3000 1400 1400 3000 - 800 3730 2360
TCC1xB218Xxx mm 2600 2200 10100 500 3000 1400 1400 3000 - 800 3730 2360
TCC1xC118Xxx mm 2600 2200 10100 500 3000 1400 1400 3000 - 800 3455 2910
TCC1xD118Xxx mm 2600 2200 10100 500 3000 1400 1400 3000 - 800 3305 3210
TCC1xD218Xxx mm 2600 2200 10100 500 3000 1400 1400 3000 - 800 3305 3210
TCC1xB120Xxx mm 2600 2200 11100 500 2000 2000 1400 1400 2700 1100 4730 2360
TCC1xB220Xxx mm 2600 2200 11100 500 2000 2000 1400 1400 2700 1100 4730 2360
TCC1xC120Xxx mm 2600 2200 11100 500 2000 2000 1400 1400 2700 1100 4455 2910
TCC1xD120Xxx mm 2600 2200 11100 500 2000 2000 1400 1400 2700 1100 4305 3210
TCC1xD220Xxx mm 2600 2200 11100 500 2000 2000 1400 1400 2700 1100 4305 3210
(1) Fan Electric Isolator(s), for unit isolation refer to (6).
(2) Mains Electric Panel(s), for unit isolation refer to (6).
(3) Bus Bar Chamber / Compressor Isolation (Inside) Electric Panel(s), for unit isolation refer to (6).
(4) Microprocessor Control Panel.
(5) Emergency Stop.
(6) Mains Cable Entry and route to Busbar, unit incoming mains isolation supplied by others.
(7) Lifting Lugs (removable): Hole 40mm Ø
12 - 18 Fan Unit x 10
(8) 20mm Ø Mounting Holes:
20 Fan Unit x 12
(9) Water Connections; grooved pipe, supplied with clamp for coupled connections and a 100mm length of counter pipe for welded connections.
(10) Optional discharge plenum
(11) Optional discharge plenum extension
(12) Water connections exit from right hand side of unit as standard, optionally connections can exit from left on request, please specify at time of enquiry.
