Chillers TURBOCHILL
Chillers
Installation Manual : 6703052 05/2008
5
Warranty
To be read in conjunction with Airedale International Air Conditioning Ltd standard
Conditions of Sale and any related quotation.
GENERAL
The equipment carries Airedale’s standard Parts (non consumable) & Labour warranty
for a period of 12 months from the date of commissioning or 18 months from the date of
despatch, which ever is the sooner. Commissioning must be carried out by Airedale or an
approved Airedale company.
1 In the period between delivery and commissioning the equipment:
is properly protected & serviced
water flow safety devices are in place and fully operational
WARRANTY IS ONLY
VALID IN THE EVENT
THAT:
2 The equipment is serviced and maintained by Airedale or an approved Airedale
company in accordance with the Installation, Commissioning & Maintenance
information provided, during the Warranty Period.
In the event of a problem being reported, Airedale will cover the full cost of rectification
(excluding costs for any specialist access or lifting equipment) if warranty is valid under
these conditions.
Any spare part supplied by Airedale under the warranty shall be warranted for the
unexpired period of the warranty or 3 months from delivery whichever period is the
longer, with the exception of compressors on which a further 12 months warranty
is granted.
• The on site contractor or service company place an official order on Airedale for the
replacement part including site labour if required. Airedale will acknowledge this
order with detailed prices for components, travel and labour rates.
• Should warranty be accepted, following inspection of the faulty component, a credit
note will be issued against the invoice raised in line with the acknowledgement.
• Should warranty be refused the invoice raised against the acknowledgement
becomes payable on normal terms.
PROCEDURE
• Airedale reserves the right to carry out site warranty labour work using their own
direct labour or by sub contracting to an approved company of their choice.
Warranty may be refused for the following reasons:
• Misapplication of product or component
• Incorrect site installation
• Incomplete commissioning documentation
• Inadequate site installation
• Inadequate site maintenance
• Damage caused by mishandling
• Replaced part being returned damaged without explanation
EXCLUSIONS
• Unnecessary delays incurred in return of defective component
Dead on arrival or manufacturing defects are the responsibility of Airedale and should be
reported immediately.
GENERAL
In the event of a warranty failure, dead on arrival or manufacturing defect, the Airedale
Service department should be contacted and on receipt of an order, an Airedale engineer
(or representative) will be directed to site as soon as possible.
RETURNS ANALYSIS
All faulty components returned under warranty are analysed on a monthly basis as a
means of verifying component and product reliability as well as supplier performance. It is
important that all component failures are reported correctly.
