TURBOCHILL Chillers

Chillers

Installation Manual : 6703052 05/2008

General Description

UNIT IDENTIFICATION

TTC1

B1 12X 95

TurboChill - Single Circuit Chiller with Centrifugal Compressor

Number of Turbocor Compressors

Evaporator Code

Number of Fans

Fan Speed (x10 rpm, ie 950 rpm)

INTRODUCTION

The Airedale range of TurboChill air cooled liquid chillers uses the technologically

superior centrifugal Turbocor compressors. Designed to cover the high capacity range of

between 500kW and 1100kW and offering over 200 model variations.

Each single circuit model is individually selected to provide the optimum solution for each

application by offering maximum flexibility and matching customer requirements in

terms of:

• Capacity

• EER/ESEER

• Sound Levels - Quiet TTC … 95 and Super Quiet … 70

• Footprint

• Pressure Drop

• Commercial considerations

REFRIGERANTS

The range has been designed and optimised for operation with ozone benign

R134a refrigerant.

Airedale certify that the equipment detailed in this manual conforms with the following

EC Directives:

Electromagnetic Compatibility Directive (EMC)

2004/108/EC

Low Voltage Directive (LVD)

73/23/EEC

Machinery Directive (MD)

89/392/EEC in the version 98/37/EC

Pressure Equipment Directive (PED)

97/23/EC

CE DIRECTIVE

To comply with these directives appropriate national & harmonised standards have been

applied. These are listed on the Declaration of Conformity, supplied with each product.
