Chillers ULTIMA COMPACT
Chillers
Installation & Maintenance : 903-129 IM E 10/04/
C
27
Installation Data
ELECTRICAL DATA
UCC160D-4/2 UCC180D-6/2 UCC200D-6/2 UCC225D-6/2 UCC250D-6/2 UCC275D-8/2
Unit Data
Nominal Run Amps (1) A 99 115 127 137 149 160
Maximum Start Amps (2) A 252 281 342 373 386 440
Permanent Supply VAC 230 V 1 PH 50 Hz
Mains Supply VAC 400 V 3 PH 50 Hz
Rec Permanent Fuse Size A 16 16 16 16 16 16
Rec Mains Fuse Size A 125 160 160 200 200 200
Max Permanent Incoming Cable Size mm² 4 mm² terminals
Max Mains Incoming Cable Size mm² Direct to Bus Bar
Control Circuit VAC 24V/230V AC
Evaporator
Pad Heater Rating W 100 100 100 100 100 100
External Trace Heating
Available (fitted by others) W 500 500 500 500 500 500
Condenser Fan - Per Fan
Quantity 4 6 6 6 6 8
Full Load Amps A 2.70 2.70 2.70 2.70 2.70 1.75
Locked Rotor Amps A 7.00 7.00 7.00 7.00 7.00 6.20
Motor Rating kW 1.60 1.60 1.60 1.60 1.60 0.98
Compressor - Per Compressor
Quantity 4 2 + 2 2 + 2 2 + 2 4 2 + 2
Motor Rating kW 11.7 15.0 / 11.7 18.2 / 11.7 18.2 / 15.0 18.2 22.8 / 18.2
Nominal Run Amps (1) A 22.0 27.0 / 22.0 33.0 / 22.0 33.0 / 27.0 33.0 40.0 / 33.0
Sump Heater Rating W 75.0 130.0 / 75.0 130.0 / 75.0 130.0 / 130.0 130.0 130.0 / 130.0
Start Amps (2) 175.0 215.0 / 175.0 270.0 / 175.0 270.0 / 215.0 270.0 320.0 / 270.0
Type Of Start Direct on line
QUIET DQ UCC160DQ-6/2 UCC180DQ-6/2 UCC200DQ-6/2 UCC225DQ-8/2 UCC250DQ-8/2 UCC275DQ-8/2
All data as above except:
Condenser Fan - Per Fan
Quantity 6 6 6 8 8 8
Full Load Amps A 1.25 1.25 1.25 1.25 1.25 1.15
Locked Rotor Amps A 4.50 4.50 4.50 4.50 4.50 2.10
Motor Rating kW 0.69 0.69 0.69 0.69 0.69 0.70
SUPER QUIET DSQ
UCC160DSQ-6/2 UCC180DSQ-6/2 UCC200DSQ-6/2 UCC225DSQ-8/2 UCC250DSQ-8/2 UCC275DSQ-10/2
All data as above except:
Condenser Fan - Per Fan
Quantity 6 6 6 8 8 10
Full Load Amps A 0.78 0.78 0.78 0.78 0.78 0.83
Locked Rotor Amps A 1.50 1.50 1.50 1.50 1.50 1.50
Motor Rating kW 0.48 0.48 0.48 0.48 0.48 0.32
OPTIONAL EXTRAS
Power Factor Correction
Nominal Run Amps (1) A 91 105 117 125 137 146
Maximum Start Amps (2) A 252 281 342 373 386 430
Recommended Mains Fuse A 125 125 160 160 200 200
Compressor Nominal Run Amps
- Per Compressor
A 4 x 20 2 x 24/2 x 20 2 x 30/2 x 20 2 x 30/2 x 24 4 x 30 2 x 36 / 2 x 30
Electronic Soft-start
Nominal Run Amps (1) A 99 115 127 137 149 160
Maximum Start Amps (2) A 182 198 234 239 278 302
Recommended Mains Fuse A 125 160 160 200 200 200
Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 105 120 132 141 154 173
Recommended Mains Fuse A 125 160 160 200 200 200
Motor Rating kW 3.0 3.0 3.0 3.0 3.0 5.5
Full Load Amps
A 6.1 6.1 6.1 6.1 6.1 11.7
Larger Single Head Pump (or Run/Standby)
Unit Nominal Run Amps (1) A 107 122 134 144 156 183
Recommended Mains Fuse A 125 160 160 200 200 250
Motor Rating kW 4.0 4.0 4.0 4.0 4.0 11.0
Full Load Amps
A 7.7 7.7 7.7 7.7 7.7 21.5
Twin Head Pump
Unit Nominal Run Amps (1) A 107 122 134 144 156 171
Recommended Mains Fuse A 125 160 160 200 200 200
Motor Rating kW 4.0 4.0 4.0 4.0 4.0 5.5
Full Load Amps
A 7.7 7.7 7.7 7.7 7.7 11.7
Larger Twin Head Pump
Unit Nominal Run Amps (1) A 110 125 137 147 159 183
Recommended Mains Fuse A 125 160 160 200 200 250
Motor Rating kW 5.5 5.5 5.5 5.5 5.5 11.0
Full Load Amps
A 11.1 11.1 11.1 11.1 11.1 21.5
(1) Based at 12/7°C water and 30°C ambient
(2) Starting amps refers to the direct on line connections.
