ULTIMA COMPACT
Chillers
46
Installation Maintenance : 903-129 IM E 10/04/C
Chillers
Parts Identification
The serial plate can be located inside Item 1.
UK MAINLAND - Chiller Maintenance Record can be located inside
Item 1.
SPARES
UCC30-UCC80 (EXCEPT 75) SINGLE & DUAL CIRCUIT
Dual Circuit Shown
1 Electrical Panel (Mains & Controls)
2 Compressors MCBs
3 Modulating Head Pressure Controller
4 Door Interlocking isolator
5 Fan Contactor MPCB
6 Incoming Customer Mains 3 Phase
7 Compressor Contactors
8 Microprocessor Controller
9 EMC Filter
10 Customer Permanent Supply/Controls Connections
11 Compressor Compartment
12 Incoming Customer Mains Access Points
13 HP Switch
14 Liquid Line Sight Glass
15 Discharge Thermostat Switch
16 Compressor Electrical Terminal Box
17 Suction Pressure Transducer & Low Pressure Switch
18 Suction Port
19 Oil Sump Draw Point
20 Oil Level Sight Glass
21 Sump Heater
22 Compressor Feet/Resilient Mounts
23 Condenser Coils
24 Water Inlet Female BSP Connection
25 Water Outlet Female BSP Connection
26 Evaporator & Optional Pump Compartment
27 Evaporator
28 Flow Switch (Optional Extra)
29 Discharge Schraeder Connection
30 Water Inlet Sensor (Inside plate heat exchanger)
31 Water Outlet Sensor (Inside plate heat exchanger)
32 Electronic Expansion Valve or Thermostatic Expansion Valve
33 Liquid Line
34 Discharge Line Ball Valve (Optional)
35 Liquid Line Filter Drier
A
spares list for 1, 3 and 5 years will be supplied with every unit and is also available
from our Spares department on request.
For ease of identification when ordering spares or contacting Airedale about your unit,
please quote the unit type, unit serial number and the date of manufacture, which can
be found on the unit serial plate.
Parts Identification
