-11-

Figure 3-6

You can check it by following the steps below:

Note:

● Is the connection between your PC and the Router correct?

The LEDs of LAN port which you link to the device and the LEDs on your PC's adapter should be lit.

● Is the TCP/IP configuration for your PC correct?

If the Router's IP address is 192.168.0.1, your PC's IP address must be within the range of

192.168.0.2 ~ 192.168.0.254, the gateway must be 192.168.0.1.

3.2 Login

Once your host PC is properly configured, please proceed as follows to use the Web-based Utility:

Start your web browser and type the private IP address of the Router in the URL field:

http://192.168.0.1.

After that, you will see the screen shown below; enter the default User Name admin and the default

Password admin.
