TL-R402M Cable/DSL Router User Guide

To Modify or delete an existing entry:

1. Find the desired entry in the table.

2. Click Modify or Delete as desired on the Edit column.

3. Click the Enable All button to enable all entries.

4. Click the Disable All button to disable all entries.

5. Click the Delete All button to delete all entries.

6. Click the Next button to go to the next page and the Previous button to return to the previous

page.

For example:

if you want to block the PCs on your LAN from accessing websites www.xxyy.com.cn,

www.aabbcc.com and websites with .net at

the end on the Inter

net while no limit for other

websites. First, enable the Firewall and Domain

Filtering on the Firewall page, then, specify

the following Domain filtering list:

4.7.4 MAC Filtering

Like the IP Address Filtering page, the MAC Address Filtering page (shown in Figure 4-25) allows

you to control access to the Internet by users on your local network based on their MAC

addresses.
