9
The are 4 LED indicators for one RJ-45 connection port. If there
is no connection to a port, the corresponding LED indicators are
not lit.
LK1000 The LED indicator is green when the Port is linking
with 1000Mbps mode. When the port is operating in
10Mbps/100Mbps mode or not connected, the LED indicator
is not lit.
ACT This LED indicator blinks green when the port is
transmitting or receiving packets. When the device is not
attached, the LED indicator is not lit.
LK100 The LED indicator is green when the Port is linking
with 100Mbps mode. When the port is operating in 10Mbps
mode or not connected, the LED indicator is not lit.
FD The LED indicator is yellow when the port is operating
in Full-duplex mode. When the port is operating in Half-
duplex mode, the LED indicator is not lit.
