13
Backpressure option and Limit4 option for half duplex
Automatic address learning with 4K address entry storage
C
HAPTER
2
P
LANNING YOUR
N
ETWORK
Before you install your DES-1200M, you should review the
guidelines for setting up Ethernet networks. Further, you should
plan your network to take maximum advantage of its switching
capabilities.
10Base-T Ethernet Network Guidelines
The maximum length of a 10Base-T cable segment is 100
meters (328 feet).
The maximum number of nodes on a 10Base-T segment is
one (1) for regular 10Base-T.
The recommended cable type is EIA/TIA Category 3 or
higher.
The maximum network diameter is 500 meters (1,640 feet)
for Ethernet networks.
The maximum number of segments between any two
nodes in the network is five.
The maximum number of hubs or repeaters between any
