two nodes in the network is four.
100Base-TX Fast Ethernet Network Guidelines
The maximum length of a 100Base-TX cable segment is
100 meters (328 feet).
The maximum number of hubs on a 100Base-TX segment
is one if using Class I hubs and two if using Class II hubs.
The recommended cable type is EIA/TIA Category 5
untwisted-pair.
The maximum network diameter is 200 meters (656 feet)
when using Class I hubs and 205 meters (672.5 feet) when
using Class II hubs.
100Base-FX Fast Ethernet Network Guidelines
In Multi-mode, the fiber optic segment cannot exceed 2 km
(62.5/125µm), 2 km (50/125µm) in length.
In Single-mode, the fiber optic segment cannot exceed
60km (9/125µm) in length.
1000BASE-SX and LX Network Guideline
1000BASE-SX
In Multi-mode, the fiber optic segment cannot exceed
220m (62.5/125µm) or 500m (50/125µm) in length.
