LED Indicators Explanation
Power
The red power indicator is illuminated when power is
provided to the switch and the switch is turned in the ON
position.
Link/Activity
Green Link/Activity indicators are illuminated when the
switch detects a connection to that
port. The indicator
blinks when data is transmitted over the network
connected to that port.
When a port is not connected, the indicator is off.
Full Duplex/Col
Red Full Duplex/Col indicators are illuminated when that
port is in full duplex mode. The indi
cator is off when that
port is in half duplex mode.
When a collision occurs on the network connected to a
port, that Full Duplex/Col indicator blinks.
100Mbps
Green 100Mbps indicators are illuminated when the port is
operating in 100Mbps mode. The indic
ator is off when the
port is operating in 10Mbps mode.
Power Port
The power port accepts the power plug.
Power Switch
The power switch, located on the rear panel, controls the power supply
