Table 1. Summary of Source and Measure Functions

Function Measure Source

Resistance 0 Ω to 4000 Ω 1 Ω to 4000 Ω

RTD

(Resistance-Temperature Detector)

Pt100 Ω (385)

Pt100 Ω (3926)

Pt100 Ω (3916)

Pt200 Ω (385)

Pt500 Ω (385)

Pt1000 Ω (385)

Ni120 Ω (672)

Pt10 Ω (385)

Pt50 Ω (385)

Cu10 Ω (427)

Cu50 Ω

Cu100 Ω

YSI400

Other functions Loop power supply, Step, Ramp, Isolated mA channel for 4-20 mA

measurement (with loop power supply)
