Fluke 712C [38/42] Ohms source

712C

Users Manual

Ohms Source

Ohms Range

Excitation Current from

Measurement Device

Accuracy

(% of Output + Floor)

1 year 2 year

1.0 Ω to 400.0 Ω 0.1 mA to 0.5 mA 0.015 % + 0.1 Ω 0.03 % + 0.2 Ω

1.00 Ω to 400.00 Ω 0.5 mA to 3 mA 0.015 % + 0.05 Ω 0.03 % + 0.08 Ω

400.0 Ω to 1500.0 Ω 0.05 mA to 0.8 mA 0.015 % + 0.5 Ω 0.03 % + 0.8 Ω

1500.0 Ω to 4000.0 Ω 0.05 mA to 0.4 mA 0.015 % + 0.5 Ω 0.03 % + 0.8 Ω

Resolution

1.00 Ω to 400.00 Ω 0.01 Ω

400.0 Ω to 4000.0 Ω 0.1 Ω

Notes:

1) Supports pulsed transmitters and PLCs with pulse times as short as 5 ms.

2) Temperature coefficient: ± (0.002 % of output + 0.002 % of range) /°C ( <18 °C or >28 °C)
