Fluke 712C [35/42] Replacement parts
![Fluke 712C [35/42] Replacement parts](/views2/1437117/page35/bg23.png)
RTD Calibrator
Maintenance
27
Replacement Parts
Table 7 lists the part number of each replaceable part.
Refer to Figure 12.
Table 7. Replacement Parts
Item Description PN Qty.
Case top
4312892
1
Decal
4312915
1
Keypad
4307147
1
Keypad support
4307112
1
Screw, M2.2 x 0.8, 5
MM, PAN, PHILLIPS
2032777
10
LCD mask
4307249
1
LCD protect rubber
4307208
1
LCD
4313462
1
Support LCD gasket
4307213
1
Screw, M3 x 0.5,5MM,
PAN, PHILLIPS
2032811
6
Case seal rubber 4307186
1
Case bottom assembly 4307079
1
Screw, M3, 13.5 mm,
PAN, PHILLIPS
2388382
6
Battery door seal rubber 4307199
1
AA battery 376756
4
Pad, battery door 4417921
1
Battery door assembly 4376901
1
Bail stand 4307093
1
Quick Reference Guide 4285056
1
--
754-8016 alligator clip
set, not shown
4253535 1
--
Stackable test lead set,
not shown
3669716 1
--
Test Leads, not shown variable
[1]
2
sets
--
Alligator Clips, not shown variable
[1]
2
sets
[1] See www.fluke.com for more information about the
test leads and alligator clips available for your region.
