RTD Calibrator
Specifications
33
Loop Power Supply
Open circuit voltage: 24 V ±10 %
Loaded circuit voltage: 18 V minimum at 20 mA current
Short circuit protected
General Specifications
Maximum voltage applied between any terminal and
earth ground or between any two terminals:
30 V
Operating temperature -10 °C to 50 °C
Storage temperature -20 °C to 60 °C
Operating altitude 2,000 meters
Storage altitude 12,000 meters
Relative Humidity (% RH operating without
condensation)
Non condensing
90 % (10 °C to 30 °C)
75 % (30 °C to 40 °C)
45 % (40 °C to 50 °C)
(Without condensation)
Vibration Requirements MIL-T-28800E, Class 2
Drop Test Requirements 1 meter
IP Rating IEC 60529: IP52
Electromagnetic Environment IEC 61326-1, Portable
Safety IEC 61010-1, Max 30 V to earth, Pollution Degree 2
Power Supply 4 AA NEDA 15A IEC LR6 batteries
Size (H x W x L)
52.5 x 84 x 188.5 mm
Weight 524 g
