D-Link DCS-950G [42/96] Trigger
![D-Link DCS-950G [42/96] Trigger](/views2/1043941/page42/bg2a.png)
42
DCS-950G User’s Manual
D-Link Systems, Inc.
Using the Configuration Menu
Trigger
Tools > Trigger
SMTP Login Name:
SMTP Password:
SMTP (Mail)
Server:
Return E-mail
address:
Recipient E-mail
address:
SMTP Port:
The user name used to log into your e-mail account (e.g. jdoe
or jdoe@yourisp.com depending on your ISP).
The password used to log into your e-mail account. (The
password will appear as dots instead of entered characters.)
The domain name or IP address of external mail server.
The return e-mail address to use if the snapshot or system log
e-mail fails to send. (This address should be within the SMTP
server’s domain for authentication purposes.)
The e-mail address of recipients for snapshots or a system
log file.
This is the port number for your SMTP server, the default is 25.
If you use ports other than 25 you can change it here.
