65
DCS-950G User’s Manual
D-Link Systems, Inc.
IPView Lite
How to take a Snap-Shot with the Camera
To take a snap shot with the camera, you must highlight the camera you wish to use
from the IPView Lite list view format. From the menu bar select Camera > Snap shot.
A Save Image dialog box will appear for you to save the snap shot picture.
Alternatively, select from the viewing mode either 1 or 4 cameras. Click on the icon
located on the upper left corner of the screen. A case sensitive menu will appear.
Select the Snap shot icon. A Save Image dialog box will appear for you to save the
snap shot picture.
To start recording with a camera you must highlight the camera you want to use from
the list view format. From the menu bar select Camera > Start. An AVI file will appear
in your IPView Lite folder to save the recorded videos.
Alternatively, in the viewing mode (using either 1 or 4 cameras), right-click on the icon
located on the upper left corner of the screen. A case sensitive menu will appear. Select
the Start icon. An AVI file will appear in your IPView Lite folder to save the recorded
videos.
Note: You must stop recording before changing any camera settings.
How to Stop Recording
To stop recording with a camera, you must highlight the camera you wish to stop from
the list view format. From the menu bar select Camera > Stop. The recording function
will be stopped.
The other alternative is to click the icon located on the upper left corner of the screen
under the viewing mode of either 1 or 4 cameras; a case-sensitive menu will appear.
Select Stop. The recording will now cease.
How to Start Recording
