Hardware Installation
Hardware Installation
Connect the Ethernet Cable
Connect the included Ethernet cable to the network cable connector located on the
back panel of the DCS-950G and attach it to the network. Network Connectivity is
confirmed when the green LED Indicator on the DCS-950G located below the Power
LED is illuminated.
Attach the External Power Supply
Attach the external power supply to the DC power input connector located on the rear
panel of the DCS-950G and connect it to your local power supply. Note: Power source
is confirmed when the orange LED Power Indicator located to the right of the lens on
the DCS-950G is illuminated.
Attach the Antenna
Locate the antenna included with your DCS-950G and attach it to the antenna connector
located on the back of the DCS-950G.
