90
DCS-950G User’s Manual
D-Link Systems, Inc.
Technical Specifications
Communication Support
Communication: 10/100Mbps Ethernet and Fast Ethernet only
2.4 802.11G Wireless 54Mbps
Communication protocol: HTTP, TCP/IP, UDP, ARP, ICMP, BOOTP,
RARP, DHCP, PPPoE
Web Configuration Requirements:
Internet Explorer 6.0 or above
CPU: Pentium II, 266 MHz or above
Memory Size: 32 MB (64 MB recommended)
VGA card resolution: 800x600 or above
ActiveX Control requires IE6.0 or above
PC Requirements for IPView Lite:
Windows XP, Windows 2000, Windows Me, Windows 98SE
Pentium III, 850 MHz CPU or above
128 MB (256 MB Recommended)
EMI & Safety: FCC, CE, VCCI
