D-Link DWL-1700AP [10/82] Network layout continued

For more information regarding installation, please see the sections on Ground-

ing and Connections in this manual, and the Quick Installation Guide that came

with your purchase.

Network Layout (continued)

Upon completion of the installation, laptops, with wireless network cards in-

stalled, will be able to connect wirelessly to the DWL-1750 in order to surf the

Internet.
