D-Link DWL-1700AP [9/82] Network layout

Mount the DWL-1750 to an unobstructed wall or mast. Make sure that is is

grounded.

Connect the DWL-1750 to the Inline Power Injector

Connect a Hub, Switch or Router to the Inline Power Injector

Connect a desktop computer to the router. You can use this Ethernet connected

computer to configure and manage the DWL-1750

Network Layout
