16
2.6 Verifying Correct Operation
2.6.1 Verifying Correct Operation of the Indoor Unit
To verify proper operation, check the LED indicators located on the top panel of the
indoor unit as shown in Figure 8 on page 14, and as described in Table 1.
Name Description Functionality
POWER Power indication
Green - 48VDC is present on the Radio
RJ45 port.
Off - No power is supplied to the Radio
RJ45 port.
LINK Self Test and Ethernet
Link indication
The LINK LED indicates end-to-end
connection between the outdoor unit and
the Ethernet connection to the indoor
unit.
Off – No Ethernet connectivity has been
detected between the outdoor unit and
the device connected to the indoor unit.
Orange– Self-test passed and Ethernet
connection is confirmed by the Outdoor
unit (Ethernet integrity check passed).
Table 1: Indoor Unit LEDs
