![D-Link DWL-1800R [51/77] Security](/views2/1044813/page51/bg33.png)
46
France 10-13
Output Power
(at the antenna
port)
FCC -4, -2, 4, 6, 12, 14, 20, 24
ETSI -4, -
2, 4, 6, 12, 14
(dBm)
Japan TELEC -4, -2, 4, 6, 12, 14
Data Rate Sensitivity Modulation
11 Mbit/s -85 dBm 256 CCK
5.5 Mbit/s -88 dBm 16 CCK
2 Mbit/s -90 dBm DQPSK
Sensitivity
(BER 10E-6)
1 Mbit/s -93 dBm DBPSK
Processing Gain
10.4 dB Nominal
Integrated
Antenna Type
Flat Panel 16 dBi, 20? Vertical /Horizontal
5.4 Range
Europe/ ETSI (20
dBm EIRP)
Up to 10 km
US FCC Up to 25 km (15 miles)
5.5 Security
Authentication
and Data
40-bit RC4 WEP
5.6 Outdoor Unit-to-Indoor Unit Communication
Cable Type
Cat 5 FTP 4x2x24 Double Jacket
Maximum Cable
length between units
90 m (280 feet)
5.7 Interfaces
RF (antenna) connector
in the outdoor unit
(DWL-1800D models)
N-Type jack, lightning protected
