50
15 miles/24Km (FCC) or 10 KM (ETSI) can be achieved using the UNI-24 antenna
kit for a point-to-point link. Consult the antenna and accessory guide range tables
for distances using other antennas.
Does the DWL-1800B supports 802.1d spanning tree protocol?
No, the DWL-1800B/DWL-1800R does not support spanning tree.
What is the normal PER (Packet Error Rate) for the
DWL-1800B/DWL-1800R?
The error rate will be about 4%-6% (transmitted fragments vs. retry count). This is typical
when operating in a non-interference environment at maximum range for bi-directional
traffic loads. If the traffic load is more uni-directional, then the PER will be less.
What is the best value for the CW min parameter on the DWL-1800?
Setting the CW min parameter to 31 for heavy bi-directional traffic loads will
minimize the PER. Setting the CW min to 15 will improve performance for more
uni-directional traffic loads. CW min 7 should only be used for short-range
point-to-point links, and 63 should be used for large, long-range multi-point links.
Is the D-Link Air Premier DWL-1800 compatible with other D-Link
wireless equipment from other vendors?
Yes. However, for the outdoor bridges, interoperability can vary from vendor to vendor
and in some cases it may not operate if the manufacturer’s implementation is not pure
802.11b. The DWL-1800B/DWL-1800R can operate at 1, 2Mbps 5.5Mbps and 11Mbps
with D-Link Air and Air Plus wireless family products. D-Link Air Premier DWL-1800
units are fully WI-FI compliant.
