Button TC1 (Lights)
Switches main light ON/OFF
When the main light is on, BL1 changes
colour and becomes active.
When the button is pressed for more than
a second, it switches the courtesy lights
(optional) on/off
Button TC2 (Motor-V1)
Motor ON/OFF - Activates the motor at 1st
speed
Button TC3 (Motor-V2)
Activates the motor at 2nd speed
Button TC4 (Motor-V3)
Activates the motor at 3rd speed
Button TC5 (Motor-V4)
Activates the motor at 4th speed
Maximum speed is timed at a maximum of
5 minutes, after which 3rd speed is set
automatically.
When the motor is active, the LED of the
last selected button (TC2-TC5) active to
signal which speed has been set.
Button TC6 (TIMER auto power off 5 min.)
Activates the TIMER function at the speed that has already been
selected
If the motor is NOT active, it switches on the motor at the 1st speed and
activates the TIMER function
When the TIMER function is active, BL6 becomes active.
30h filter ALARM
After 30 hours of operation, an alarm switches on to signal the need for
anti-grease filter cleaning.
The filter alarm, when active, is displayed for 30 sec each time the motor
is deactivated:
BL6 remains ON.
During this period, it is possible to reset the alarm by pressing the TC6
button for longer than a second.
120h filter ALARM
After 120 hours of operation, an alarm switches on to signal the need for
active carbon filter (optional) replacement.
The filter alarm, when active, is displayed for 30 sec each time the motor
is deactivated:
BL6 lighting blinking.
During this period, it is possible to reset the alarm by pressing the TC6
button for longer than a second
Work Time Limit
If the hood is left on (lights and/or motor), after 10 hours in the absence
of commands from the user, it will automatically switch to OFF condition
with all services switched off.
Buzzer
The Buzzer emits a "beep" each time that a command is set from the
keyboard or remote control (optional)
P1: Pressed lightly
switches lights on and off,
switches the P1 LED on and off
P2: Pressed with the engine off: starts the engine
at the first speed. Pressed with the engine at the first
speed: switches the engine off. Pressed with the engine
at speed¹ of the first speed will set the engine at the first
speed. The speed is indicated by the LED on.
P3: Pressed with the engine off: starts the engine
at the second speed. Pressed with the engine at speed¹
of the second speed will set the engine at the second
speed. The speed is indicated by the LED on
P4: Pressed with the engine off: starts the engine
at the third speed. Pressed with the engine at speed¹
of the third speed will set the engine at the third speed.
The speed is indicated by the LED on.
P5: Pressed with the engine off: starts the engine
at the fourth speed. Pressed with the engine at speed¹
of the fourth speed will set the engine at the fourth
speed. The speed is indicated by the LED on.
P6: Activates/deactivates the timer 5’ function and
indicates this with P6 on.
P7: Reset filters: when the filter alarm is active
(30 or 120), resets the counter and switches off the
corresponding LED.
If the engine is off, if the Timer 5’ function is on the engine
will start at the first speed.
Buzzer:
A “bip” will sound each time this button is pressed.
Filter alarm visualization:
After 30 hours of engine operation, LED P7 will switch
on for 30” when the engine is switched off. anti-grease
filters alarm
After 120 hours of engine operation, LED P7 will flash
for 30” when the engine is switchef off.
carbon
filters alarm
To RESET the alarm, press P7 during alarm display.
