you will not be able to use the features configured in the Firewall and Filters menus

located in the Advanced directory. See the next chapter for more details on these

menus.

10. Typically the globally IP settings (i.e. IP address for the WAN interface) for a

PPPoA or PPPoA connection will use Dynamic IP assignment from the ISP.

Some accounts may be assigned a specific global IP address. If you have been

give an IP address for you PPPoE/PPPoA connection, select the Static IP option

from the IP Control pull-down menu. This menu can be used to configure the WAN

port as an Unnumbered IP interface. (See table below for Unnumbered IP)

11. Most users will not need to change ATM settings. If this is the first time you are

setting up the ADSL connection it is recommended that you leave the Service

Category settings at the default values until you have established the connection.

See the table on page 22 for a description of the parameters available for ATM

traffic shaping.

12. When you are satisfied that all the WAN settings are configured correctly, click on

the Apply button.

13. The new settings must be saved and the Router must be restarted for the settings

to go into effect. To Save & Reboot the Router, click on the Tools directory tab

and then click the Save & Reboot menu button. In the Save and Reboot menu,

click the Reboot button under Force the DVA-G3340S to system restart. The

Router will save the new settings and restart. Upon restarting the Router will

automatically establish the WAN connection.

Additional settings for PPPoE/PPPoA connections:

PPPoE/PPPoA Parameters Description

User Name

For PPP connections, a User Name and Password are

used to identify and verify your account to the ISP.

Enter the User Name for your ADSL service account.

User names and passwords are case-sensitive, so

enter this information exactly as given to you by your

ISP.

Password

Together with the User Name, this is used to verify

your account to the ISP. Enter the Password exactly

as given to you by your ISP.

Connection Type

This specifies the protocol (PPPoE or PPPoA) and the

encapsulation method (LLC or VC-MUX) used for your

connection. The options available are PPPoE LLC,

PPPoA LLC or PPPoA VC-MUX.
