D-Link DI-604UP [10/61] Getting started

Getting Started

Installation Location

The DI-604UP can be positioned at any convenient place in your office or

house. No special wiring or cooling requirements are needed. However,

you should comply with the following guidelines:

 Place the DI-604UP on a flat horizontal plane.

 Keep away from any heating devices.

 Do not place in a dusty or wet environment.

The recommended operational specifications of the DI-604UP are:

Temperature 32 ~ 113℉℉

Humidity 10% ~ 95%

In addition, remember to turn off the power, remove the power cord from

the outlet, and keep your hands dry when you install the hardware.

Network Settings

To use the DI-604UP correctly, you have to properly configure the network

settings of your computers. The default IP address of the DI-604UP is

192.168.0.1, and the default subnet mask is 255.255.255.0. These

addresses can be changed as needed, but the default values are used in

this manual. If the TCP/IP environment of your computer has not yet been

configured, you can refer to Configuring Your PCs to Connect to the

DI-604UP to configure it.

For example:

1. Configure your computer IP as 192.168.0.3, subnet mask as

255.255.255.0 and gateway as 192.168.0.1

Or more conveniently

2. Configure your computers to obtain TCP/IP settings automatically

from the DHCP server feature of the DI-604UP

Since the IP address of the DI-604UP is 192.168.0.1, the IP address of your

computer must be 192.168.0.X (where “X” is a number between 2 and

254.) Each computer on your network must have a different IP address

within that range. The default gateway must be 192.168.0.1 (the IP

address of the DI-604UP).
