Using the Configuration Wizard

The DI-604UP provides an embedded Web-based management utility

making it operating system independent. You can configure your DI-604UP

through the Netscape Communicator or Internet Explorer browser in MS

Windows, Macintosh, Linux or UNIX based platforms. All that is needed is

a web browser such as Internet Explorer or Netscape Navigator version 4

and higher with Java Script enabled.

Start-up and Log in

Activate your web browser and type in the IP address of the DI-604UP into

the Location (for Netscape) or Address (for IE) field and press “Enter.” The

default IP address of the DI-604UP is

192.168.0.1

After the connection is established, the logon screen will pop up.

To log in as an administrator, enter the username of “admin” and the

password (there are no default password, leave it blank). Click the OK

button. If the password is correct, the web-management interface will

appear.

Open your Web

browser and type

“http://192.168.0.1” into

the URL address box.

Then press the Enter or

Return key.

Type “admin” for

the username and

leave the password

field blank.

Click OK
