Pioneer DEH-P8400MP [2/52] Connecting the units

Connecting the Units ................................ 1

Installation .................................................. 5

Installation with the rubber bush ...................... 5

Removing the Unit ............................................ 6

About the fixing screws for the front panel ...... 6

Installing the

Steering Remote Control Unit .......... 7

Installing the Unit on a

Left-Hand-Drive Car .................................. 8

Connecting the Units

Contents

Note:

• This unit is for vehicles with a 12-volt battery and

negative grounding. Before installing it in a recre-

ational vehicle, truck, or bus, check the battery

voltage.

• To avoid shorts in the electrical system, be sure to

disconnect the ≠ battery cable before beginning

installation.

• Refer to the owner’s manual for details on con-

necting the power amp and other units, then make

connections correctly.

• Secure the wiring with cable clamps or adhesive

tape. To protect the wiring, wrap adhesive tape

around them where they lie against metal parts.

• Route and secure all wiring so it cannot touch any

moving parts, such as the gear shift, handbrake,

and seat rails. Do not route wiring in places that

get hot, such as near the heater outlet. If the insu-

lation of the wiring melts or gets torn, there is a

danger of the wiring short-circuiting to the vehi-

cle body.

• Don’t pass the yellow lead through a hole into the

engine compartment to connect to the battery.

This will damage the lead insulation and cause a

very dangerous short.

• Do not shorten any leads. If you do, the protec-

tion circuit may fail to work when it should.

• Never feed power to other equipment by cutting

the insulation of the power supply lead of the unit

and tapping into the lead. The current capacity of

the lead will be exceeded, causing overheating.

• When replacing fuse, be sure to use only fuse of

the rating prescribed on this unit.

• Since a unique BPTL circuit is employed, never

wire so the speaker leads are directly grounded or

the left and right ≠ speaker leads are common.

Pioneer DEH-P8400MP [2/52] Connecting the units
