SOFTWARE FEATURES
Operation Mode 3G/4G Router, Wireless Router
DHCP
Server, Client, DHCP Client List,
Address Reservation, DHCP relay
Quality of Service Traffic Control(IP QoS)
Port Forwarding Virtual server, Port Triggering, DMZ, ALG, UPnP
VPN Pass-through PPTP, L2TP, IPSec Pass-through
Dynamic DNS DynDns, NO-IP
IPSec VPN Supports up to 10 IPSec VPN tunnels
Guest Network
2.4GHz guest network × 1
5GHz guest network × 1
Security
Access Control, MAC Filtering,
IP and MAC Address Binding
Management
Web Based Configuration (HTTP), Remote management,
Command Line Interface,
SSL for TR-069, SNMP v1/2, Web Based Firmware Upgrade, Diagnostic Tools
IPv6 IPv6 and IPv4 dual stack
Advanced Features
Parental Controls
Network Address Translation (NAT); Port Mapping (Grouping), Static Routing,
RIP v1/v2;
DNS Relay, DDNS, IGMP V1/V2/V3,
Physical and Environment
Operating
Temperature
0℃ ~ 40℃
Working Humidity 10% ~ 90% RH (non-condensing)
Storage Temperature
-40℃ ~ 70℃
Storage Humidity 5% ~ 90% RH (non-condensing)
*Only 2.412GHz~2.462GHz is allowed to be used in USA, which means only channel 1~11 is available for American
users to choose.
