Service options
Service options improve the level of service response, extend the warranty period, or provide calibration reports. You can order
service options when you purchase an oscilloscope, or purchase a service option at a later date.
Service options
Option name Description
T3 Three year Total Protection Plan. Includes preventative maintenance, and repair or replacement
coverage from wear and tear, accidental damage, and ESD or EOS damage. Includes a five-day
turnaround time and priority access to customer support.
T5 Five year Total Protection Plan. Includes preventative maintenance, and repair or replacement
coverage from wear and tear, accidental damage, and ESD or EOS damage. Includes a five-day
turnaround time and priority access to customer support.
R5 Standard warranty is extended to five years. Covers parts, labor, and 2-day shipping within country.
Guarantees faster repair time than without coverage. All repairs include calibration and updates.
Hassle free - a single call starts the process.
C3 Three-year calibration service. Includes traceable or functional verification where applicable, for
recommended calibrations. Coverage includes the initial calibration plus two years calibration
coverage.
C5 Five-year calibration service. Includes traceable or functional verification where applicable, for
recommended calibrations. Coverage includes the initial calibration plus four years calibration
coverage.
D1 Factory calibration data report for the instrument.
D3 Three years of calibration data reports (with Option C3)
D5 Five years of calibration data reports (with Option C5)
R5DW Repair service coverage for five years (includes the standard product warranty period). The five year
period starts at time of instrument purchase.
How to install an option license
Use this process install an option license (Node (instrument) locked or Floating) to enable specific instrument features. Option
licenses provide advanced functions for specific standards or measurement requirements.
Prerequisites:
■
A license file for each option. Contact Tektronix Customer Service to purchase and obtain option license file(s). Node
Locked option licenses are specific to the oscilloscope serial number, and cannot be used on other oscilloscopes. Floating
licenses can be used on any instrument, but can only be checked out to one instrument at a time.
License (.lic) files are the Tektronix AMS tool at www.tek.com/products/product-license. There is a how-to
video on this site to help you with your license file install.
■
To access the user interface on a Low Profile instrument, connect a monitor to a video port on the rear of the instrument,
and connect a mouse to any USB Host port. You do not need to connect a mouse if your remote monitor is touch-capable.
You can also remotely access the user interface of a network-connected instrument by entering the instrument's IP address
in a web browser.
