(3) To remove the bit, place the chuck wrench into one

of the holes in the chuck and turn it in the

counterclockwise direction.

For keyless chuck (Fig. 2)

(1) Mounting the bit

Turn the sleeve counterclockwise and open the chuck.

After inserting the drill bit into the chuck as far it will

go, grip the ring and close the chuck by turning the

sleeve clockwise as viewed from the front.

(2) Dismounting the bit

Grip the ring and open the chuck by turning the

sleeve counterclockwise.

NOTE

When the sleeve does not become loose any further,

fix the side handle to ring, hold side handle firmly,

then turn the sleeve to loosen by hand (Fig. 3).

6. Check the rotational direction (Fig. 4)

The bit rotates clockwise (viewed from the rear side)

by pushing the R-side of the push button.

The L-side of the push button is pushed to turn the bit

counterclockwise.

(The

and

marks are provided on the body.)

7. Fixing the side handle (Fig. 5)

Attach the side handle to the mounting part.

Rotate the side handle grip in a clockwise direction

to secure it.

Set the side handle to a position that is suited to the

operation and then securely tighten the side handle

grip.

To attach a depth gauge on the side handle, insert

the gauge into the U-shaped groove on the side

handle, adjust the position of the depth gauge in

accordance with the desired depth of the hole, and

firmly tighten the side handle grip (Fig. 6)

8. High-speed/Low-speed changeover

Prior to changing speed, ensure that the switch is in

the OFF position, and the drill has come to a complete

stop.

To change speed, rotate the gear shift dial as indicated

by the arrow in Fig. 7. The numeral “1” engraved on

the drill body denotes low speed, the numeral “2”

denotes high speed.

Voltage (by areas)* (110V, 220V, 230V, 240V)

Power input 790 W*

Speed change 1 2

No load speed

Forward rotation 0 – 1000 min

-1

0 – 3000 min

-1

Reverse rotation 0 – 600 min

-1

0 – 1800 min

-1

Capacity

Steel 13 mm 8 mm

Wood 40 mm 25 mm

Weight (without cord) 2.0 kg

STANDARD ACCESSORIES

(1) Chuck Wrench (Spec. only for keyed chuck) ........... 1

(2) Side Handle ................................................................ 1

(3) Depth Gauge .............................................................. 1

Standard accessories are subject to change without

notice.

APPLICATIONS

䡬 Boring holes in metal, wood and plastic.

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position. If

the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, inviting serious accident.

3. Extension cord

When the work area is removed from the power

source, use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

4. Selecting the appropriate drill bit

䡬 When boring metal or plastic

Use an ordinary metalworking drill bit.

䡬 When boring wood

Use an ordinary woodworking drill bit.

However, when drilling 6.5 mm or smaller holes, use

a metalworking drill bit.

5. Mounting and dismounting of the bit

For keyed chuck (Fig. 1)

(1) Open the chuck jaws, and insert the bit into the

chuck.

(2) Place the chuck wrench in each of the three holes

in the chuck, and turn it in the clockwise direction

(viewed from the front side). Tighten securely.

SPECIFICATIONS

*Be sure to check the nameplate on product as it is subject to change by areas.

DRILL SAFETY WARNINGS

1. Use auxiliary handles supplied with the tool.

Loss of control can cause personal injury.

2. Before drilling into walls, ceilings or floors, ensure

that there are no concealed power cables inside.

3. Do not wear gloves made of stuff liable to roll up

such as cotton, wool, cloth or string, etc.

01Eng_D13VB3_WE 08/12/18, 19:345
