Figure 6-6 802.1Q VLAN PVID Setting

The following entries are displayed on this screen:

 802.1Q VLAN PVID Setting

Select:

Select the desired port for configuration. It is multi-optional.

Port:

Displays the port number.

PVID:

Enter a PVID number for the port. When adding the tag header

to the received untagged packet, the switch will automatically

uses this PVID value as the VLAN ID of the added tag.

LAG:

Displays the LAG to which the port belongs.

Note:

1. 802.1Q VLAN should be enabled before setting PVID.

2. You can go to Switching→LAG page to configure the LAG status of the port.
