RxBadPkt: Displays the number of error packets received on the port.

Note:

1. The frames with more than 1518 bytes, less than 64 bytes or with bad Frame Check

Sequence (FCS) are recorded as BadPkts.

2. Because of the supporting feature of jumbo frame, the frames with more than 1518 bytes

and less than 10000 bytes will be recorded as GoodPkts and BadPkts at the same time,

and can be forwarded normally.

5.2 Port Mirror

Port mirror function is to monitor and mirror network traffic by forwarding copies of incoming

and outgoing packets from one/multiple ports (mirrored port) to a specific port (mirroring port).

Usually, the mirroring port is connected to a data diagnosis device, which is used to analyze

the mirrored packets for monitoring and troubleshooting the network.

Choose the menu Monitoring→Port Mirror to load the following page.

Figure 5-2 Port Mirror (for TL-SG105E/TL-SG108E/TL-SG108PE)
