Egress Rate(Kbps):

Configure the bandwidth for sending packets on the port. You

can select a rate from the dropdown list or select "Manual" to set

Egress rate, the system will automatically select integral multiple

of 64Kbps that closest to the rate you entered as the real

Egress rate.

LAG: Displays the LAG number which the port belongs to.

Note:

When egress bandwidth control feature is enabled for one or more ports, you are suggested to

disable the flow control on each port to ensure the switch works normally.

7.3 Storm Control

Storm Control function allows the switch to filter broadcast, multicast and UL frame in the

network. If the transmission rate of the three kind packets exceeds the set bandwidth, the

packets will be automatically discarded to avoid network broadcast storm.

On this page you can configure and view the storm control function information.

Choose the menu QoS→Storm Control to load the following page.

Figure 7-6 Storm Control Setting

The following entries are displayed on this screen:

 Storm Control Config

Select:

Select the desired port for Storm Control configu

ration. It is

multi-optional.
