Chapter 8 PoE

Note:

Only TL-SG1016PE supports configuring PoE function.

PoE (Power over Ethernet) technology describes a system to transmit electrical power along

with data to remote devices over standard twisted-pair cable in an Ethernet network. It is

especially useful for supplying power to IP telephones, wireless LAN access points, cameras

and so on.

 Composition

A PoE system usually consists of PSE and PD.

PSE: Power sourcing equipment (PSE) is a device such as a switch that provides power on the

Ethernet cable to the linked device.

PD: A powered device (PD) is a device accepting power from the PSE and thus consumes

energy. PDs fall into two types, standard PDs and nonstandard PDs. Standard PDs refer to the

powered devices that comply with IEEE 802.3af and IEEE 802.3at. Examples include wireless

LAN access points, IP Phones, IP cameras, network hubs, embedded computers etc.

 Advantage

 Cheap cabling: The remote device such as cameras can be powered by PSE in no

need of prolonging its power cord additionally and Ethernet cable is much cheaper

than AC wire or power cord.

 Easy to connect: PoE uses only one Ethernet cable with no need of external power

supply.

 Reliable: A powered device can be either powered by PSE using Ethernet cable or

powered through the provided power adapter. It is very convenient to provide a

backup power supply for the PDs.

 Flexibility: In compliance with IEEE 802.3af and IEEE 802.3at, global organizations can

deploy PoE everywhere without concern for any local variance in AC power standards,

outlets, plugs, or reliability.

 Wide use: It can be applied to wireless LAN access points, IP Phones, IP cameras,

network hubs, embedded computers etc.

TL-SG1016PE is a Power Sourcing Equipment (PSE). Ports 1-8 on the switch support Power

over Ethernet (PoE) function, which can automatically detect and supply power for those

powered devices (PDs) complying with IEEE 802.3af and IEEE 802.3at. The maximum power

TL-SG1016PE can supply is 110W and the maximum power each PoE port can supply is 30W.
