Chapter Introduction

Chapter 5 Monitoring This module is used to monitor the traffic information of the

switch, and

provide the convenient method to locate and

solve the network problem.

 Port Statistics: View the statistic information of each port.

 Port Mirr

or: Monitor and mirror network traffic by

forwarding copies of incoming and outgoing packets

from one/multiple ports (mirrored port) to a specific port

(mirroring port).

 Cable Test: Diagnose the connection status of the cable

connected to the switch and the distance to the problem

location.

 Loop Prevention: Detect loops using loopback detection

packets, and then display an alert or further block the

corresponding port.

Chapter 6 VLAN

This module is used to configure VLANs to control

broadcast in LANs. Here mainly introduces:

 MTU VLAN: Set the MTU VLAN mode.

 Port Based VLAN: Set the Port-Based VLAN mode

 802.1Q VLAN: Set the 802.1Q Tag VLAN mode.



802.1Q PVID Setting: Configure 802.1Q PVID value.

Chapter 7 QoS This module is used to configure QoS function to provide

different quality of service for various network applications

and requirements. Here mainly introduces:

 QoS Basic: Configure and view the basic parameters of

QoS.

 Bandwidth Control: Configure and view the bandwidth

control function information.

 Sto

rm Control: Configure and view the storm control

function information.

Chapter 8 PoE

This module is used to configure the PoE function for the

switch to supply power for PD devices.

Chapter 9 Help Lists the help and version information of the utility.
