Rigol DS1104B [106/168] Language

RIGOL

User’s Guide for DS1000B series

2-76

Language

The DS1000B series oscilloscopes have multi-language user menu, choose as your

desire.

Press Utility → Language to select the language. Press button No.4 until the desired

language appears.

Figure 2-100 Language selection screen
