Rigol DS1104B [22/168] To display a signal automatically

RIGOL

User’s Guide for DS1000B series

1-10

To Display a Signal Automatically

The oscilloscope has an automated feature to display the input signal in best-fit

status. The input signal should be 50 Hz or higher and a duty cycle is greater than

1%.

Using the automatic setting:

1. Connect a signal to the oscilloscope (such as channel 1) as described above.

2. Press Auto.

The oscilloscope may change the current settings to display the signal; adjusts the

vertical and horizontal scaling, the trigger coupling, type, position, level, and mode.
