RIGOL

User’s Guide for DS1000B series

1-12

Measurement hints

If the channel is DC coupled, measuring the DC components of the signal by

simply noting its distance from the ground symbol.

If the channel is AC coupled, the DC component of the signal is blocked,

allow you to use greater sensitivity to display the AC component of the

signal.

Vertical offset back to 0 shortcut key

Turn the

knob to change the vertical display position of

channel and press the

knob to set the vertical display

positi

on back to 0 as a shortcut key, this is especially helpful when the trace

position is far out of the screen and want it to get back to the screen center

immediately.

3. Set vertical “Volts/div” by

knob.

Rotate

to change “Volts/div”, the change will be displayed in real

time at the bottom of interface. Besides, the “Volts/div” contains two forms:

“Fine” and “Coarse”.

Coarse/Fine Shortcut key

The Coarse/Fine vertical control can be set by simply pressing the vertical

knob.
