RIGOL

User’s Guide for DS1000B series

2-52

Figure 2-63

Adopt Normal acquisition

Figure 2-64

Adopt peak detect acquisition, signal contains envelope

Key points

Stop Acquisition:

When the scope is acquiring waveforms, the

waveforms is in a live status; when acquisition is stopped, frozen waveform

will be displayed, the position and scale can still be adjusted by vertical

control and horizontal control.
